Tread Code |
Ply Rating |
Spd |
Measure Rim |
Inflated Dimensions(mm) SW /OD |
Max.Load(kg) 10/50(km/h) |
Pressure(kPa) 10/50(km/h) |
Standard Complied | Type Tube | Type Tubeless |
|
E-3.L-3 |
9.00-20NHS |
16 |
7.0 |
259/1038 |
3130 |
770 |
Q/KCS004 | * | |
| E-3.L-3 | 10.00-20NHS | 16 | 7.5 | 278/1073 | 3460 | 740 | Q/KCS004 | * | |
| E-3.L-3 | 11.00-20NHS | 18 | 8.0 | 293/1104 | 3940 | 800 | Q/KCS004 | * | |
| E-3.L-3 | 12.00-20NHS | 18 | 8.5 | 315/1145 | 5900 | 800 | Q/KCS004 | * | |
| E-3.L-3 | 17.5-25 | 12 | 14.00/1.5 | 445/1350 | 6150/3650 | 350/225 | GB/T2980 | * | * |
| E-3.L-3 | 17.5-25 | 16 | 14.00/1.5 | 445/1350 | 7300/4250 | 475/300 | GB/T2980 | * | * |
| E-3.L-3 | 20.5-25 | 16 | 17.00/2.0 | 520/1490 | 8250/5450 | 350/275 | GB/T2980 | * | * |
| E-3.L-3 | 20.5-25 | 20 | 17.00/2.0 | 520/1490 | 9500/6000 | 450/325 | GB/T2980 | * | * |
| E-3.L-3 | 23.5-25 | 16 | 19.50/2.5 | 595/1615 | 9500/6150 | 300/225 | GB/T2980 | * | * |
| E-3.L-3 | 23.5-25 | 20 | 19.50/2.5 | 595/1615 | 10900/7300 | 375/300 | GB/T2980 | * | * |
