Size |
Ply Rating |
Speed index |
Standard Rim |
Inflation Pressure(kPa) |
Max.Load(kg) |
Inflated Section Width(mm) |
Overall Diameter,Inflated(mm) |
Pattern Depth(mm) |
| 10.00R20 | 16 | L | 7.5 | 830/770 | 3000/2725 | 275 | 1052 | 15.5 |
| 10.00R20 | 18 | L | 7.5 | 930/930 | 3250/3000 | 275 | 1052 | 15.5 |
| 11.00R20 | 16 | L | 8.0 | 830/770 | 3350/3075 | 286 | 1082 | 16.5 |
| 11.00R20 | 18 | L | 8.0 | 930/930 | 3550/3250 | 286 | 1082 | 16.5 |
| 12.00R20 | 18 | L | 8.5 | 830/770 | 3750/3450 | 313 | 1122 | 15.0 |
| 11.00R22 | 16 | K | 8.0 | 830/770 | 3270/2870 | 293 | 1085 | 16.5 |
| 11.00R22 | 18 | K | 8.0 | 930/930 | 3550/3250 | 293 | 1085 | 16.5 |
| 11R22.5 | 14 | M | 8.25 | 720 | 2800/2650 | 279 | 1050 | 14.5 |
| 11R22.5 | 16 | M | 8.25 | 830 | 3000/2725 | 279 | 1050 | 14.5 |
| 11R24.5 | 14 | M | 8.25 | 720 | 3000/2725 | 279 | 1100 | 14.5 |
| 11R24.5 | 16 | M | 8.25 | 830 | 3250/3000 | 279 | 1100 | 14.5 |
| 12R22.5 | 14 | M | 9.00 | 800/800 | 3350/3000 | 300 | 1084 | 15.0 |
| 12R22.5 | 16 | M | 9.00 | 850/850 | 3550/3150 | 300 | 1084 | 15.0 |
| 295/75R22.5 | 14 | M | 9.00 | 760/760 | 2800/2575 | 298 | 1014 | 14.0 |
| 295/75R22.5 | 16 | M | 9.00 | 830/830 | 3000/2725 | 298 | 1014 | 14.0 |
| 285/75R24.5 | 14 | M | 8.25 | 760/760 | 2800/2575 | 283 | 1050 | 14.5 |
| 285/75R24.5 | 16 | M | 8.25 | 830/830 | 3075/2800 | 283 | 1050 | 14.5 |
| 295/80R22.5 | 14 | M | 9.00 | 800/800 | 3350/3000 | 298 | 1044 | 14.5 |
| 295/80R22.5 | 16 | M | 9.00 | 850/850 | 3550/3150 | 298 | 1044 | 14.5 |
| 315/80R22.5 | 18 | M | 9.00 | 825/825 | 3750/3350 | 312 | 1076 | 14.5 |
| 315/80R22.5 | 20 | M | 9.00 | 850/850 | 4000/3350 | 312 | 1076 | 14.5 |
