Size |
Ply Rating |
Speed index |
Load Index |
Standard Rim |
Max.Load(kg) |
Inflation Pressure(kPa) |
Inflated Section Width(mm) |
Overall Diameter,Inflated(mm) |
Pattern Depth(mm) |
| 9.00R20 | 14 | K | 140/137 | 7.0 | 2575/2255 | 810/740 | 259 | 1018 | 15.5 |
| 9.00R20 | 16 | K | 144/142 | 7.0 | 2800/2650 | 900/900 | 259 | 1018 | 15.5 |
| 10.00R20 | 16 | K | 146/143 | 7.5 | 3000/2630 | 840/770 | 278 | 1055 | 15.5 |
| 10.00R20 | 18 | K | 149/146 | 7.5 | 3250/3000 | 930/930 | 278 | 1055 | 15.5 |
| 11.00R20 | 16 | K | 149/145 | 8.0 | 3270/2870 | 840/770 | 293 | 1085 | 16 |
| 11.00R20 | 18 | K | 150/149 | 8.0 | 3550/3250 | 930/930 | 293 | 1085 | 16 |
