Size |
Ply Rating |
Speed index |
Load Index |
Standard Rim |
Max.Load(kg) |
Inflation Pressure(kPa) |
Inflated Section Width(mm) |
Overall Diameter,Inflated(mm) |
Pattern Depth(mm) |
| 7.50R16LT | 14 | L | 121/117 | 6.00G | 1495/1310 | 740/740 | 225 | 805 | 14 |
| 8.25R16LT | 14 | L | 126/122 | 6.50H | 1705/1500 | 670/670 | 235 | 855 | 14 |
| 8.25R16LT | 16 | L | 128/124 | 6.50H | 1800/1600 | 770/770 | 235 | 855 | 14 |
| 7.50R20 | 14 | L | 129/125 | 6.0 | 1855/1655 | 840/770 | 215 | 935 | 14 |
| 8.25R20 | 14 | K | 135/130 | 6.5 | 2205/1940 | 840/770 | 232 | 971 | 14 |
| 8.25R20 | 16 | K | 139/137 | 6.5 | 2430/2300 | 930/930 | 232 | 971 | 14 |
| 9.00R20 | 14 | K | 140/137 | 7.0 | 2575/2255 | 810/740 | 259 | 1018 | 15.5 |
| 9.00R20 | 16 | K | 144/142 | 7.0 | 2800/2650 | 900/900 | 259 | 1018 | 15.5 |
| 10.00R20 | 16 | K | 146/143 | 7.5 | 3000/2630 | 840/770 | 278 | 1055 | 16 |
| 10.00R20 | 18 | K | 149/146 | 7.5 | 3250/3000 | 930/930 | 278 | 1055 | 16 |
| 11.00R20 | 16 | K | 149/145 | 8.0 | 3270/2870 | 840/770 | 293 | 1085 | 17.5 |
| 11.00R20 | 18 | K | 152/149 | 8.0 | 3550/3250 | 930/930 | 293 | 1085 | 17.5 |
| 12.00R20 | 18 | K | 154/149 | 8.5 | 3790/3270 | 840/770 | 315 | 1125 | 17.5 |
| 11R22.5 | 16 | L | 146/143 | 8.25 | 3000/2630 | 840/770 | 279 | 1050 | 15 |
| 11R22.5 | 16 | M | 148/145 | 8.25 | 3150/2900 | 850/850 | 279 | 1050 | 15 |
