Size |
Ply Rating |
Speed index |
Load Index |
Standard Rim |
Max.Load(kg) |
Inflation Pressure(kPa) |
Inflated Section Width(mm) |
Overall Diameter,Inflated(mm) |
Pattern Depth(mm) |
| 10R22.5 | 14 | L | 141/136 | 7.50 | 2575/2255 | 810/740 | 254 | 1020 | 14.5 |
| 10R22.5 | 16 | L | 144/142 | 7.50 | 2800/2650 | 860/860 | 245 | 1020 | 14.5 |
| 12R22.5 | 16 | M | 149/145 | 9.00 | 3270/2870 | 840/770 | 300 | 1084 | 15 |
| 12R22.5 | 16 | M | 152/148 | 9.00 | 3550/3150 | 850/850 | 300 | 1084 | 15 |
| 13R22.5 | 18 | L | 154/150 | 9.75 | 3750/3350 | 860/860 | 320 | 1124 | 16 |
| 13R22.5 | 18 | M | 152/148 | 9.75 | 3550/3150 | 850/850 | 320 | 1124 | 16 |
| 295/80R22.5 | - | L | 152/148 | 9.00 | 3550/3150 | 850/850 | 298 | 1044 | 15 |
| 295/80R22.5 | 16 | M | 152/148 | 9.00 | 3550/3150 | 850/850 | 298 | 1044 | 15 |
| 275/70R22.5 | - | L | 148/145 | 8.25 | 3150/2900 | 900/900 | 276 | 958 | 15 |
| 275/70R22.5 | 16 | M | 148/145 | 8.25 | 3150/2900 | 900/900 | 276 | 958 | 15 |
| 315/80R22.5 | 18 | L | 154/151 | 9.00 | 3750/3450 | 830/830 | 312 | 1076 | 15 |
| 315/80R22.5 | 18 | M | 154/150 | 9.00 | 3750/3350 | 825/825 | 312 | 1076 | 15 |
| 315/80R22.5 | 20 | L | 156/153 | 9.00 | 4085/3715 | 900/900 | 312 | 1076 | 15 |
