Size |
Ply Rating |
Speed index |
Load Index |
Standard Rim |
Max.Load(kg) |
Inflation Pressure(kPa) |
Inflated Section Width(mm) |
Overall Diameter,Inflated(mm) |
Pattern Depth(mm) |
| 295/80R22.5 | L | 152/148 | 9.00 | 3550/3150 | 850/850 | 298 | 1044 | 19 | |
| 295/80R22.5 | 16 | M | 152/148 | 9.00 | 3550/2150 | 850/850 | 298 | 1044 | 19 |
| 11R22.5 | 16 | L | 146/143 | 8.25 | 3000/2630 | 840/770 | 279 | 1050 | 19 |
| 11R22.5 | 16 | M | 148/145 | 8.25 | 3150/2900 | 850/850 | 279 | 1050 | 19 |
| 315/80R22.5 | 18 | L | 154/151 | 9.00 | 3750/3450 | 830/830 | 312 | 1076 | 19 |
| 315/80R22.5 | 18 | M | 154/150 | 9.00 | 3750/3350 | 825/825 | 312 | 1076 | 19 |
| 315/80R22.5 | 20 | L | 156/153 | 9.00 | 4085/3715 | 900/900 | 312 | 1076 | 19 |
